Semiconductor Electronics Quiz-1

Semiconductor Electronics Quiz-1

Difficulty Level: Easy
10 Questions
4 Plays
QuizardQuizard

Popular Questions InSemiconductor Electronics Quiz-1

1

An intrinsic semiconductor is at a temperature of 27∘C27^\circ C27∘C. The probability of an electron jumping from valence band to conduction band

2

The impurity atoms with which pure silicon should be doped to make a n-type semiconductor are those

3

For the same dopant concentration, the n-type silicon semiconductor has ..................... as compared to a p-type silicon semiconductor.

4

At thermal equilibrium, the concentration of majority carriers in an n-type extrinsic semiconductor is

5

In a p-type semiconductor, the concentration of holes is2×1015cm−32 \times 10^{15} cm^{-3}2×1015cm−3. The intrinsic carrier concentration is 2×1010cm−32 \times 10^{10} cm^{-3}2×1010cm−3. The concentration of electrons will be.

6

In a semiconductor doped with phosphorous the Fermi–level is 0.3 eV below condition band 27∘C27^\circ C27∘C. The temperature is raised by 30∘C30^\circ C30∘C. The new Fermi–level is

7

The width of depletion region in a p–n junction diode is 500 nm and an intense electric field of 6×1056\times10^56×105 V/m is also found to exist. The height of potential barrier is

8

In a junction diode, I is current when applied forward bias voltage is V at a temperature T on Kelvin scale. Then

9

A silicon PN diode has a reverse saturation current of 20  μA20\;\mu A20μA at a temperature of 20∘C20^\circ C20∘C. The reverse saturation current of the same diode at a temperature of 40∘C40^\circ C40∘C will be,

10

For a Zener diode; which of the following statements is correct?
